5SelectWhiteLineand/orBottomLinetosuityourpreferences.
6Applythechange(s)youhavemade.
aSelectApplyifyouwishtoapplythechosensettingonlytothecurrentlyactive
echogramview.
bSelectApplytoAllifyouwishtousethechosensettingonalltheechograms
ofthesametype.
7Closethedialogbox.
Addingverticalmarkerlinestotheechogram
Inordertocreateahorizontalscale,youcanaddshortverticalmarkerlinestoyour
echogram.Theselinesareusedtomeasuretimeordistance.
Context
Thefollowingoptionsareavailable:
•None:Noverticalmarkersareshown.
•Time:Ashortverticallineisdrawnintheupperpartoftheechogramonceevery
speciednumberofminutes.
•Distance:Ashortverticallineisdrawnintheupperpartoftheechogramonceevery
speciednumberofnauticalmiles.
Note
Thisisavisualenhancement.ItdoesnothaveanyeffectontheES80performance.
Procedure
1Clickonceintheechogramviewthatyouwishtochange.
Thiswillmaketheview"active".Athickborderisplacedontheselectedview
tovisualizethis.
2OpentheActivemenu.
3SelectEchogram.
ObservethattheEchogramdialogboxopens.
4OntheleftsideoftheEchogramdialogbox,selectLinestoopenthepage.
5Selecttheverticalmarkerlinesyouwishtouse.
Operatingprocedures
