Simrad ES80 User Manual

120
406273/C
6Applythechange(s)youhavemade.
aSelectApplyifyouwishtoapplythechosensettingonlytothecurrentlyactive
echogramview.
bSelectApplytoAllifyouwishtousethechosensettingonalltheechograms
ofthesametype.
7Closethedialogbox.
Addinghorizontaldepthlinestotheechograms
Whenenabled,equidistanthorizontalscalelinesaredrawninsidetheechograminthe
currentforegroundcolour;blackduringdayandwhiteduringnight.
Context
Amaximumof10scalelinescanbeselected.Noscalelinesaredrawnwhenthescale
linecountissetto0(zero).
Note
Thisisavisualenhancement.ItdoesnothaveanyeffectontheES80performance.
Procedure
1Clickonceintheechogramviewthatyouwishtochange.
Thiswillmaketheview"active".Athickborderisplacedontheselectedview
tovisualizethis.
2OpentheActivemenu.
3SelectEchogram.
ObservethattheEchogramdialogboxopens.
4OntheleftsideoftheEchogramdialogbox,selectLinestoopenthepage.
5SelectScaletoenablethefunction,andchoosehowmanyscalelinesyouwishtosee.
6Applythechange(s)youhavemade.
aSelectApplyifyouwishtoapplythechosensettingonlytothecurrentlyactive
echogramview.
bSelectApplytoAllifyouwishtousethechosensettingonalltheechograms
ofthesametype.
7Closethedialogbox.
SimradES80ReferenceManual
