Simrad ES80 User Manual

62
406273/C
InstallingtheES80operationalsoftware
IfyourES80WidebandshndingechosounderisprovidedwithaProcessorUnit,the
ES80softwarehasalreadybeeninstalled.Ifyouintendtouseyourowncomputer,you
mustinstallthesoftwareyourself.
Prerequisites
Inordertoinstallthesoftware,youneedtherelevantlesetonasuitablemedia.Ifthe
softwareisprovidedonaCDoraDVD,andyourcomputerisnotttedwithasuitable
drive,copythelestoaUSBashdrive.
Note
MakesurethatyouhaveadministrativerightsontheProcessorUnit.Youneedthisto
installthesoftware.Ifyoupurchasedyourowncomputer ,youmustverifythatitmeets
thetechnicalrequirementsforusewiththeES80.Dothisbefore
youinstallthesoftware.
Context
OneormorevalidsoftwarelicensesarerequiredtooperatetheES80.Thesoftware
licensesareinstalledaftertheES80softwareinstallation.TheSoftwareLicensepageis
providedforthispurpose.
Procedure
1TurnontheProcessorUnit.
2Switchoffanyrewallapplications.
3InserttheES80softwaremedia.
IftheES80softwareisprovidedonaCDorDVD,andyourProcessorUnitisnot
ttedwithasuitabledrive,copythelestoaUSBashdrive.
4UsealemanagerapplicationontheProcessorUnittoaccessthesoftwareles.
5Double-clickSetup.exetostarttheinstallation.
Note
Iftheoperatingsystemonyourcomputerisnotsupported,theinstallationwillstop
withanerrormessage.Youmustthenupgradeyourcomputer-oruseadifferent
one-tocompletethesoftwareinstallation.
6Allowtheinstallationwizardtorun.Followtheinstructionsprovided.
Werecommendthatyouinstallthesoftwareinthedefaultfoldersuggestedbythe
wizard.Inthelastdialogboxyouarepermittedtoremoveoldsettings.Sincethisis
yourrstinstallationofthesoftware,youcandisregardthisoption.
7Oncethesoftwareinstallationhasbeencompleted,double-clicktheicononthe
desktoptostarttheprogram.
8Dependingonyouroperatingsystemparameters,certaindialogboxesmayopen.
SimradES80ReferenceManual

Simrad ES80 Specifications

General

Operating Temperature	-15°C to +55°C
Type	Echosounder
Transceiver	External
Applications	Fisheries research, commercial fishing
Depth Range	Up to 3000 meters
Interface	Ethernet, NMEA 2000
Frequency Range	18 kHz, 38 kHz, 70 kHz, 120 kHz, 200 kHz, 333 kHz
