Simrad ES80 User Manual

510
406273/C
19chksum:Checksum
Thechecksumeldconsistsofa"*"andtwohexdigitsrepresentingtheexclusive
ORofallcharactersbetween,butnotincluding,the"$"and"*"characters
Note
Thisdatagramformatisobsolete,anditisnolongerinuseonnewdesigns.Ithas
beenreplacedbydatagramPSIMP-D1.
Relatedtopics
Proprietarydatagramformats,page504
SensorInstallationpage,page363
SensorCongurationpage,page369
RelayOutputpage,page395
Interfacespecications,page473
SimradPSIMP-Fdatagramformat
SimradPSIMP-FisaproprietarydatagramformatcreatedbyKongsbergMaritime
toprovidethetypeandcongurationofPSandPIsensorsusedbyaSimradcatch
monitoringsystem.
Format
$PSIMP,F,S1,S2,S3,T1,T2,T3,F1,F2,F3*chksum<CR><LF>
Description
Note
Thisdatagramdescriptionisnotcomplete.Ifyouneedfurtherinformation,contact
KongsbergMaritime.
1PS:Talkeridentier
2IMP:Datagramidentier
3F:Sentencespecier
4S1,S2,S3:sensortypes
•D:Depth300m
•E:Depth600m
•T:Temperature
•C:Catchslow
•F:Catchfast
SimradES80ReferenceManual
