Simrad ES80 User Manual

406273/C
183
8OntheleftsideoftheOutputdialogbox,selectOlexOutput.
9OntheOlexOutputpage,setuptheportparameters.
aSelectthecommunicationport.
bSelectAdd
cSelectApply.
dSelectOKtosavetheselectedsettingsandclosethedialogbox.
Note
TheOlexsystemwillonlyacceptinformationfromCWtransmissions.Ifyouattempt
toexportdatafromaLFMchannelitwillrespondwithanerrormessage.
SynchronizingtheES80bymeansofaserialport
IfyouwanttousetheES80asamasterorslaveinasynchronizedsystem,youmustset
itupforsuchoperation.Todothis,youmustselectwhichcommunicationporttousefor
thesynchronizationinterface,andyoumustselecttherequestedsynchronizationmode.
Prerequisites
Thisprocedureassumesthat:
•Thevesselisberthedoratsea.
•YouhaveanRS2-232interfaceportonyourProcessorUnitthatallowsyoutousethe
CTS/RTSconnections.
For"slave"operation,aremotesystem(forexampleK-Sync)mustbeavailableto
providetriggerpulses.For"master"operation,aremotehydroacousticsystem(sonar,
echosounder)isconnected.Thisremotesystemmustbesetupin"slave"mode.
Context
Whenevermorethanonehydroacousticsystemisinstalledonavessel,interferencemay
occur.Toavoidinterference,youhavetheseoptions:
•Thesystemsareallconnectedtoacommonsynchronizationsystem.
•Oneoftheacousticsystemsissetupas"master",andcontrolsthetransmissionson
theothersystems.
TheES80offersfunctionalityforremotetransmitsynchronization.Itcanbesetupto
operateineitherMasterorSlavemode.
Note
TheWideBandTransceiver(WBT)offersan Auxiliary portthatcanbeusedfor
synchronisationpurposes.Thissynchronizationmethodmaybemorestablethatthe
traditionalCTS/RTSconnectiontoaserialport.
Operatingprocedures

Simrad ES80 Specifications

General

Operating Temperature	-15°C to +55°C
Type	Echosounder
Transceiver	External
Applications	Fisheries research, commercial fishing
Depth Range	Up to 3000 meters
Interface	Ethernet, NMEA 2000
Frequency Range	18 kHz, 38 kHz, 70 kHz, 120 kHz, 200 kHz, 333 kHz
