Recordingandreplayingrawechodata
Topics
Deningtheleandfoldersettingsfordatarecording,page97
Recordingechodata,page98
SelectingReplaymode,page100
Choosingwhichechodatale(s)toreplay,page100
Accessingtheechodatalestodelete,moveorcopythem,page102
Deningtheleandfoldersettingsfordatarecording
TheRecordfunctionallowsyoutorecordechodata.ThedataaresavedontheProcessor
Unitharddisk-oronanexternaldatastoragedevice-accordingtothepreferences
youhavedened.
Context
TheFileSetupparameterscontrolhowandwheretherecordedlesaresavedonthe
ProcessorUnitharddisk,oronanexternaldisk.Byaddingalenameprex,youcan
alsoidentifylesrecordedfromanyspecicmissionorsurvey.Youcanalsodenea
maximumsizeofthedatales.
Tip
Dataleswillnormallybecomeverylarge.IfyouwishtorecordlargeamountsofES80
data,makesurethatyouhaveenoughspaceonyourharddisk.UnlessyourProcessor
Unitisequippedwithaverylargedisk,werecommendthatyousavethedatatoan
externalstoragedevice.
Setuptheleandfolderparametersbefore
youstarttherecording.Ifyouwishto
saveyourrecordeddataonanexternalharddisk,makesurethatitisconnectedto
theProcessorUnit.
Ifthecurrentlesizegetstoobigduringrecording,usetheSplitFilefunctiononthe
Recordbutton.Thiswillclosethecurrentle,andthenautomaticallycontinuerecording
toanewle.TheRecordfunctionislocatedontheOperationmenu.
DonotconfusetheRecordfunctionwiththeautomaticHistoryfunction.Unlessyou
reallyneedtorecordrawdataforplaybackpurposes,youshouldusethisfunctionwith
care.Thedataleswillllyouharddiskveryfast!TheHistoryfunctionsavesthe
echogramimages
automaticallyontheProcessorUnitharddiskTheseimagescanbe
recalledusingtheHistoryinformationpane.TheinformationintheHistorypresentation
isthesameasontheoriginalechogrampresentation.
