406273/C
275
Relateddialogboxes
Echogramdialogbox,page419
Echogram:HorizontalAxispage,page428
RangeOtherLinedescription
Wheneveryouworkwithsurfaceandbottomechogramssimultaneously,youmayîš¿ndit
usefultohaveanoverviewoftherangesettings.TheRangeOtherLinefunctionplaces
rangeindicatorsfortheBottomechogramintoyourSurfaceechogram.
Howtoopen
ToactivatetheRangeOtherLinefunction,clickinthe
echogramviewtomakeit"active".
SelectEchogramontheActivemenu.SelecttheLines
tabtoopenthepage.OntheLinespage,enablethe
RangeOtherLinefunction.
Description
ThisfunctionisusedwhenyousetupyourES80withbothasurfacerelatedandbottom
relatedechogramshownsimultaneously.Whenenabled,twohorizontallinesinthe
surfaceechogramindicatetherangeselectedinthebottomechogram.
Thisisavisualenhancement.ItdoesnothaveanyeffectontheES80performance.
Relatedtasks
Enhancingthebottomcontourintheechograms,page118
Addingverticalmarkerlinestotheechogram,page119
Addinghorizontaldepthlinestotheechograms,page120
Addingavariabledepthlinetotheechogram,page121
Relateddialogboxes
ManualAnnotationdialogbox,page342
Installationdialogbox,page346
Annotationspage,page382
Echogramdialogbox,page419
Echogram:Echogrampage,page424
Userinterface
