406273/C

501

NMEAVHWdatagram

TheNMEAVHWdatagramcontainsthecompassheadingtowhichthevesselpoints,

andthespeedofthevesselrelativetothewater.

Format

$--VHW,x.x,T,x.x,M,x.x,N,x.x,K*hh<CR><LF>

Description

1$—:Talkeridentier

2VHW:Datagramidentier

3x.x,T:Heading(DegreesTrue)

4x.x,M:Heading(DegreesMagnetic)

5x.x,N:Speedrelativetowater(knots)

Resolution:0.1knots

6x.x,K:Speedrelativetowater(km/hr),

Resolution:0.1km/hr

7*hh:Checksum

Relatedtopics

NMEAdatagramformats,page491

SensorInstallationpage,page363

SensorCongurationpage,page369

RelayOutputpage,page395

Interfacespecications,page473

NMEAVLWdatagram

TheNMEAVLWdatagramcontainsthetravelleddistanceofthevessel.

Format

$--VLW,x.x,N,y.y,N,z.z,N,g.g,N*hh<CR><LF>

Description

1$—:Talkeridentier

2VLW:Datagramidentier

3x.x,N:Waterdistance,Totalcumulative(Nauticalmiles)

4y.y,N:Waterdistance,Sincereset(Nauticalmiles)

Datagramformats
