3SelectScreenCapturetomakeacopyofthecurrentES80presentation.
Everytimeyoudothis,anewimageleiscreated.
Result
Thescreencapturesyoumakearesavedin.jpgformatontheharddiskintheProcessor
Unit.Eachcaptureincludestheentirevisiblepresentation.Itincludesthecurrent
echogramsandthemenu.
Recallingsingleechogramscreencaptureimages
TheScreenCapturefunctiononthetopbarallowsyoutomakeacopyofthecurrent
ES80presentation.Thescreencapturesyoumakearesavedin.jpgformatonthehard
diskintheProcessorUnit.TheScreenCapturestabonthebottombaropensaviewer
thatallowsyoutoopentheseimages.
Context
Thescreencapturebrowsersimplypresentsaminiatureversionofeachscreencapture
thatyouhavemade.EachleisprovidedinstandardJPGformat,whichcanbeopened
bymostcommercialbitmapeditors.Thelenamesarecreatedautomaticallyusingthe
dateandtimewhenyouusedtheScreenCapturebutton.
Procedure
1ObservetheScreenCapturestabatthebottomoftheES80presentation.
2SelecttheScreenCapturestabtoopenthescreencapturebrowser.
3Double-clicktheimageyouwishtoenlarge.
4SelectReturntoBrowsertoclosetheimage.
5ToresumenormalES80operation,selectanyothertabonthebottombar.
Accessingthescreencaptureimagestodelete,moveor
copythem
Oncethescreencaptureimageshavebeensaved,youmayalsowishtodeletethem,copy
them,ormovethemfromtheProcessorUnittoaseparatestoragedevice.
Prerequisites
ItisassumedthatyouarefamiliarwiththeMicrosoft
®
operatingsystemutilitiesfor
lehandling.
