Relateddialogboxes
Echogramdialogbox,page419
Echogram:Echogrampage,page424
BottomLinedescription
TheBottomLinecanbeaddedtoyourechogramtoenhancethevisualbottomdetection.
Howtoopen
ToactivatetheBottomLine,clickintheechogram
viewtomakeit"active".
SelectEchogramontheActivemenu.SelecttheLines
tabtoopenthepage.OntheLinespage,enablethe
BottomLinefunction.
Description
TheBottomLineappearsasthinlinethatfollowsthebottomcontour.Thelineisdrawnin
thecurrentforegroundcolour.YoucanusetheWhiteLineandtheBottomLinefunctions
simultaneously.TheBottomLinecannot
beusedtogetherwiththeHardnessLine.
Thisisavisualenhancement.ItdoesnothaveanyeffectontheES80performance.
Relatedtasks
Enhancingthebottomcontourintheechograms,page118
Addingverticalmarkerlinestotheechogram,page119
Addinghorizontaldepthlinestotheechograms,page120
Addingavariabledepthlinetotheechogram,page121
Relateddialogboxes
ManualAnnotationdialogbox,page342
Installationdialogbox,page346
Annotationspage,page382
Echogramdialogbox,page419
Echogram:Echogrampage,page424
