406273/C

499

Description

1$—:Talkeridentier

2RMC:Datagramidentier

3hhmmss.ss:CoordinatedUniversalTime(UTC)ofthecurrentposition

4A:Status

A=Thedataarevalid.

V=Thedataarenotvalid.

5llll.ll,a:LatitudeNorth/South(Degrees,minutesandhundredths)

N=North

S=South

6yyyyy.yy,a:LongitudeEast/West(Degrees,minutesandhundredths)

W=West

E=East

7x.x:Speedoverground(knots)

8z.z:Courseoverground(DegreesTrue)

9ddmmyy:Date

10r.r,a:Magneticvariation,East/West(Degrees)

E=East

W=West

11a:Modeindicator

12*hh:Checksum

Relatedtopics

NMEAdatagramformats,page491

SensorInstallationpage,page363

SensorCongurationpage,page369

RelayOutputpage,page395

Interfacespecications,page473

NMEAVBWdatagram

TheNMEAVBWdatagramcontainswaterreferencedandgroundreferencedvessel

speeddata.

Format

$--VBW,x.x,z.z,A,r.r,q.q,A,p.p,A,c.c,A*hh<CR><LF>

Datagramformats
