Simrad ES80 - Vertical Tick Description

406273/C
279
VerticalTickdescription
Inordertocreateahorizontalscale,youcanaddshortverticalmarkerlinestoyour
echogram.Theselinesareusedtomeasuretimeordistance.
Howtoopen
ToactivatetheV erticalTickfunction,clickinthe
echogramviewtomakeit"active".
SelectEchogramontheActivemenu.SelecttheLines
tabtoopenthepage.OntheLinespage,enablethe
VerticalTickmarkersbyselectingthetypeofmarkers
youwishtosee.
Description
Thisfunctionplacesshortverticalmarkersonthetopoftheechogram.Theselinesare
usedtomeasuretimeordistance.
•None:Noverticalmarkersareshown.
•Time:Ashortverticallineisdrawnintheupperpartoftheechogramonceevery
speciednumberofseconds.
•Distance:Ashortverticallineisdrawnintheupperpartoftheechogramonceevery
speciednumberof1/10nauticalmiles.
Thisisavisualenhancement.ItdoesnothaveanyeffectontheES80performance.
Relatedtasks
Enhancingthebottomcontourintheechograms,page118
Addingverticalmarkerlinestotheechogram,page119
Addinghorizontaldepthlinestotheechograms,page120
Addingavariabledepthlinetotheechogram,page121
Relateddialogboxes
ManualAnnotationdialogbox,page342
Installationdialogbox,page346
Annotationspage,page382
Echogramdialogbox,page419
Echogram:Echogrampage,page424
