Informationpanes
TheES80offersseveralinformationpanestoprovideadditionalanddetaileddatafrom
theES80presentation.Theinformationpanesareopenedandclosedusingthebuttons
onthetopbar.
Beforeyouopenaninformationpane,youmustrstclickinanechogramviewtomake
it"active".Bydoingthisyouselectthechannel.Inthiscontext,thephrasechannel
isusedasacommontermtoidentifythecombinationoftransceiver,transducerand
operatingfrequency.
Selecttherelevantbuttononthetopbartoopentheinformationpane.
Inmostcases,thedataintheinformationpaneisonlyvalidfortheselectedchannel.
Toclosetheinformationpane,selectthebuttononthetopbaronemoretime.Youcan
alsoselectCloseinthetoprightcornerofthepane.
TheES80offersthefollowinginformationpanes(fromleft).
•History
TheHistoryinformationpaneallowsyoutoviewpreviouslyrecordedechogram
sequences.Donotconfusethisfunctionwiththerecordingfunctionality.TheHistory
functionsavestheechogramimagesautomaticallyontheProcessorUnitharddisk
TheinformationintheHistorypresentationisthesameasontheoriginalechogram
presentation.
Historyinformationpanedescription,page234
•ColourScale
TheColourScaleinformationpaneallowsyoutoviewthecurrentcolourscalein
use,andtomakechangestotheecholevelsitpresents.
ColourScaleinformationpanedescription,page235
•Depth
TheDepthinformationpaneprovidesthewaterdepthinthecurrentechogramview.
Ifyouhaveseveralechogramviewsopen,youcanplaceonepaneineachview.
Depthinformationpanedescription,page237
•Biomass
TheBiomassinformationpanedisplaysanindexofthebiomassinthecurrent
echogramview.ThebiomassindexisthesameastheNASC(Nauticalareascattering
strength)withunitm
2
/nmi
2
.
Biomassinformationpanedescription,page239
