•I/OSetup
Inordertocommunicatewithperipheraldevices,theProcessorUnitoffersseveral
serialand/orEthernet(LAN)ports.Thenumberofcommunicationportsdependson
howyourProcessorUnitissetupandcongured.TheI/OSetupsettingsallowyouto
denewhichinformationisimportedbytheProcessorUnit.Foreachport,youcanset
upthecommunicationparameters,andmonitorthedataow.
ThispageislocatedintheInstallationdialogbox.Thispageisalsolocatedinthe
Outputdialogbox.
I/OSetuppage,page371
•DepthOutput
TheES80canexportdepthinformationonadedicatedcommunicationport(serialor
Ethernet)TheDepthOutputpageisusedtosetuptheoutputparameters.
DepthOutputpage,page391
•RelayOutput
TheES80allowsyoutoexportthesamesensordatathatwasoriginallyimported.
Thiscan"reuse"thesameinformationonothersystems.TheRelayOutputpageis
usedtosetupandcontrolthisexportfunctionality.
RelayOutputpage,page395
•OlexOutput
TheES80allowsyoutoexportdatatotheproprietaryOlexsystem.Theoutput
parametersforthedataexportaredenedintheOutputdialogbox.
OlexOutputpage,page397
FileSetuppage
AusefulfunctionoftheES80isitabilitytorecordechodata.Toretrievethedatales,
youneedtoknowwheretheyare,andwhichlenamesthathavebeenused.Thepurpose
oftheFileSetupsettingsistodenetheleandfolderpropertiesfortheechodatales
thatyouarerecording.Youcanselectthediskandfolderfortheles,youcandenethe
maximumlesize,andyoucanchooseaprexforthelenames.
Prerequisites
TheOutputdialogboxisnotavailablewhenyourES80issettoInactivemode.
Howtoopen
ThispageislocatedintheOutputdialogbox.TheOutputdialogboxislocatedon
theSetupmenu.
