406273/C
83
Note
NotethatInactiveoperatingmodeisnotthesameasPassivemode.WhileInactive
modestopsbothtransmissionandreception,PassivemodewillstillallowtheES80
toreceiveechoes.
ToselectPassivemode,usetheNormalOperationdialogbox.
Procedure
1OpentheOperationmenu.
2SelectOperation,andsetittoInactive.
Result
WhentheES80hasbeendisabledusingthisfunction,itwillstop.Thetransmission
("pinging")stops.Thecurrentechoeswillberemovedfromthepresentation.
Relatedtopics
Operationfunction,page315
SelectingReplaymode
TheReplaymodeallowsyoutoplaybackpreviouslyrecordedrawdata.TheES80isnot
operationalwhileinReplaymode.Neithertransmissionnorreceptiontakesplace.
Context
Allplaybackiscontrolledbythereplaybar.
AStop:Selectthisbuttontostoptheplayback.
BPlay/Pause:Selectthisbuttontostarttheplayback,ortopauseit.
CReplayspeed:Selectthissliderandmoveitsidewaystoadjustthereplayspeed.
DReplayîš¿le:Thisbuttonshowswhichîš¿leyouarecurrentlyplaying.
EProgress:Thisbarshowsyouthereplayprogressofthecurrentîš¿le.
Procedure
1OpentheOperationmenu.
Operatingprocedures

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Simrad ES80 and is the answer not in the manual?

Simrad ES80 Specifications

General IconGeneral
BrandSimrad
ModelES80
CategoryMarine Equipment
LanguageEnglish
