Description
TheHistoryfunctionsavestheechogramimages
automaticallyontheProcessor
UnitharddiskTheseimagescanberecalledusingtheHistoryinformationpane.
TheinformationintheHistorypresentationisthesameasontheoriginalechogram
presentation.
Inordertoshowyoutherecordedechograms,theechogrampresentationissplitintwo.
Therightsidewillshowyoutheactiveechogram,whiletheleftsideisusedtodisplay
therecordedhistory.Movethesliderbuttonatthebottomofthepresentationtoviewthe
fullextentoftheimage.
Note
Thenumberofhistorylesislimited.Afterreachingthemaximumnumberofles,the
latestechogrampictureoverwritestheoldestone.Thehistoryfunctionstillallowsyouto
quicklylookthroughechogrampicturesfromseveralhours.
EverytimetheHistoryleissavedtotheharddisk,thepingingmaybeinterrupted.Itis
thereforepossibletodisabletheHistoryfunction.ThisfunctionislocatedontheFile
SetuppageintheOutputdialogbox.TheOutputdialogboxislocatedontheSetupmenu.
Relatedtasks
Increasingthevisibilityoftheinformationpanes,page145
Retrievingthelatestechogramhistory,page127
Disablingtheautomaticechogramhistoryrecording,page128
ColourScaleinformationpanedescription
TheColourScaleinformationpaneallowsyoutoviewthecurrentcolourscaleinuse,
andtomakechangestotheecholevelsitpresents.
Howtoopen
ToopentheColourScaleinformationpane,clickinthechosenviewtoactivate
it,thenselecttheColourScalebuttononthetopbar.Toclosetheinformation
pane,selectthebuttononthetopbaronemoretime.YoucanalsoselectClose
inthetoprightcornerofthepane.
Userinterface
