406273/C

Tip

Ifnotransceiversarelisted:

•SelectBrowseintheTransceiverBrowsingbox,andopentheLocalIPAddress

box.SelectthecorrectaddressfortheEthernetadapteryouareusing.Thiswill

maketheES80searchthenetworkforavailabletransceivers.

•Checkthateachtransceiverhasbeenturnedon.

•VerifythattheEthernetcommunicationbetweentheunitsisoperational.

•IfyouareusinganEthernetswitch,makesurethatitworks.

5Atthebottomofthepage,selectApplytosaveyoursettings.

6Repeatuntilallthechannelshavebeeninstalled.

7ContinueyourworkintheInstallationdialogbox,orselectOKtocloseit.

Result

Whenallchannelshavebeeninstalled,youcanstartnormaloperation.

Caution

YoumustneverstartES80transmissions("pinging")whentheshipisindrydock.The

transducermaybedamagedifittransmitsinopenair.

DeningtheserialandEthernet(LAN)portparameters

Foranysensorinterfacetowork,thecommunicationparametersmustbesetupcorrectly.

TheES80softwareautomaticallyscanstheProcessorUnittolocateandidentifythe

availablecommunicationports.Oncethesoftwarehasestablishedalistofvalid

interfaces,youcansetupandcontrolthecommunicationparameters.

Prerequisites

Thisprocedureassumesthat:

•YouhaveavacantinterfaceportonyourProcessorUnit.

•YouarefamiliarwithNMEAandotherrelevantdatagramformats.

•Youknowhowtosetuptheparametersforserialandlocalareanetwork(LAN)

communication.

•Thecommunicationparametersrequiredforthesensorinterfaceareknown.

Context

TheI/OSetuppageprovidestwolists;oneforserialportsandoneforEthernet

(LAN)ports.Eachlistissupportedwithasetoffunctionstosetupandmonitorthe
