Simrad ES80 User Manual

406273/C
511
•B:Bottom
•N:Nosensor
5T1,T2,T3:Telemetrychannelnumbersforsensors1,2and3
6F1,F2,F3:Offsetvaluesforsensors1,2and3
7chksum:Checksum
Thechecksumeldconsistsofa"*"andtwohexdigitsrepresentingtheexclusive
ORofallcharactersbetween,butnotincluding,the"$"and"*"characters
Relatedtopics
Proprietarydatagramformats,page504
SensorInstallationpage,page363
SensorCongurationpage,page369
RelayOutputpage,page395
Interfacespecications,page473
SimradTDSdatagramformat
SimradTDSisaproprietarydatagramformatcreatedbyKongsbergMaritimetoprovide
thedoorspread.Thatisthedistancebetweenthetwotrawldoors.
Format
@IITDS,x.x,M<CR><LF>
Description
1II:Talkeridentier
2TDS:Datagramidentier
3x.x,M:Distanceinmeters
Note
Inadualtrawlsystem,thedistancebetweentheseconddoorsetisprovidedindatagram
SimradTS2.
Relatedtopics
Proprietarydatagramformats,page504
SensorInstallationpage,page363
SensorCongurationpage,page369
RelayOutputpage,page395
Interfacespecications,page473
Datagramformats
