498

406273/C

2HDM:Datagramidentier

3x.x,M:Heading(DegreesMagnetic

4*hh:Checksum

Relatedtopics

NMEAdatagramformats,page491

SensorInstallationpage,page363

SensorCongurationpage,page369

RelayOutputpage,page395

Interfacespecications,page473

NMEAHDTdatagram

TheNMEAHDTdatagramprovidesthetruevesselheading.Theinformationis

normallyprovidedbyacoursegyro.

Format

$--HDT,x.x,T*hh<CR><LF>

Description

1$—:Talkeridentier

2HDT:Datagramidentier

3x.x,T:Heading(DegreesTrue)

4*hh:Checksum

Relatedtopics

NMEAdatagramformats,page491

SensorInstallationpage,page363

SensorCongurationpage,page369

RelayOutputpage,page395

Interfacespecications,page473

NMEARMCdatagram

TheNMEARMCdatagramtransfersthetime,date,position,courseandspeeddatafrom

aglobalnavigationsatellitesystem(GNSS)receiver.

Format

$--RMC,hhmmss.ss,A,llll.ll,a,yyyyy.yy,a,x.x,z.z,ddmmyy,r.r,a,a*hh
