Spectracom SecureSync User Manual

6.
Proceed with the SW configuration of the STL settings, as described below.
Note: The RJ-45 MAINT. connector will not be needed for the STL con-
figuration. Use this connector only if so requested by Spectracom Service
personnel.
Configuring STL Settings
Note: If you do not yet have a subscription key, you will need to obtain one
before continuing with installation. Please contact Orolia customer service:
stlsubscription@orolia.com
US: +1 585 321 5800; France: +33 (0)1 64 53 3980
Note: During the initial installation of a unit equipped with an STL card, the exact
geographic position needs to be entered into the Web UI (see below). Should the
unit be relocated at a later point in time, the position must be changed accord-
ingly.
The STL option card 1204-3E is configured via the SecureSync WebUI. See "The SecureSync
Web UI" on page18 for basic SecureSync setup and initial login information.
SecureSync User Reference Guide 489
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
