098-00028-000 Revision F – May, 2012 TimeProvider 5000 User’s Guide 149
Chapter 3
TimeProvider 5000 CLI Command Set
 To provision the SSM state for the specified input port:
set input ssm port[1|2] [enable|disable]
 To provision the SSM Bit position for E1 signals for the specified input port (used
only for ESF, CCS or CAS framing type):
set input ssm-bit port[1|2] [4|5|6|7|8]
 To set the forced PQL value for the specified input port:
set input pql-value port[1|2] <pql-value>
where pql-value is from 1 to 9
Example 1:
To set the priority to 1 for input port 2:
tp5000> set input priority port2 1
Example 2:
To provision the state to Enable for input port 1:
tp5000> set input state port1 enable
Example 3:
To set the frame type to 2048 kHz for input port1:
tp5000> set input frametype port1 freq2048khz
Example 4:
To provision the CRC state to Enable for input port2:
tp5000> set input crc port2 enable
Example 5:
To provision the forced PQL state to Disable for input port1:
tp5000> set input pql-state port1 disable
Note: Synchronization Status Message (SSM) is only supported for
the frametypes ESF, CAS with CRC4 and CCS with CRC4. SSM
should not be enabled for other input frame types.
If SSM is enabled for an input port and the frametype does not
support SSM or is not sending a valid SSM, then the input will be
disqualified and the input SSM will be set to 15 (invalid). The system
will go to holdover if there is not another qualified reference to switch
to.
