188 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Chapter 3
TimeProvider 5000 CLI Command Set
If the output frame type supports SSM and SSM is enabled for the output port, then
the output signal will contain the system SSM value. The table below shows the
output SSM value based on the clock state of the TP5000
Command Syntax:
To provision the state for the specified E1 or 1PPS+TOD output port:
set output-exp {e1| pps-tod} state exp[0-9] {port [1-12] |
all} {enable | disable}
To provision the framework for the specified E1 output port:
set output-exp e1 frametype exp[0-9] {port [1-12] | all}
{freq2048khz|cas|ccs}
7 0x10 0x0B Type IV/Stratum 3
8 0x22 0x0F G.813OPT3/SMC
9 0x30 0x0F DUS, Do not Use for Sync
15 --- --- Did not receive valid SSM
Clock State Output SSM
Warm-up PQL=9 - Do not use for Sync (DUS)
Free-run PQL of oscillator
Fast-lock PQL of reference
or PRS for GPS mode
Normal PQL of reference
or PRS for GPS mode
Bridging Last PQL of reference
Holdover PQL of reference
Note: The default output frame type is freq2048khz.
