Symmetricom TimeProvider 5000 User Manual

098-00028-000 Revision F – May, 2012 TimeProvider 5000 User’s Guide 187
Chapter 3
TimeProvider 5000 CLI Command Set
show output-exp
This command displays the E1 or 1PPS+TOD output port configuration and status
in E1-TOD expansion shelf.
Command Syntax:
show output-exp { e1 | pps-tod } exp[0-9]
Example:
tp5000> show output-exp e1 exp0
Level : User, Config, and Admin
set output-exp
Use this command to provision the E1 and 1PPS+TOD output ports on the
expansion shelf. This command allows you to provision:
 state
 frame type
 CRC (for CAS or CCS frametypes only)
 SSM (for frame type ESF, CCS with CRC, or CAS with CRC)
 SSM-bit (for frame type ESF, CCS with CRC, or CAS with CRC)
 output generation behavior in warm-up, free-run, fast-track, and holdover states
Priority Quality Level (PQL) values are listed in the following table.
Quality Level DS1 SSM E1 SSM Description
1 0x04 0x02 Stratum 1/PRS/PRC
2 0x08 0x00 STU, Stratum Unknown (presumed ST1)
3 0x0C 0x04 Stratum 2/Type II
4 0x0C 0x04 Type I
5 0x78 0x04 Transit Node/Type V
6 0x7C 0x08 Type III/Stratum 3E
