264 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Chapter 3
TimeProvider 5000 CLI Command Set
tp5000> set vlan-mode ioc1-1 enable
Example 2:
To add a fixed VLAN on IOC1-1 with VLAN ID = 25, Index=3, Priority=0, where the
IP address= 192.168.1.5 Netmask=255.255.255.0, and Gateway=192.168.1.1 
tp5000> set vlan-config add ioc1-1 index 3 vlan-id 25
priority 0 address 192.168.1.5 netmask 255.255.255.0 gateway
192.168.1.1
Example 2a:
To add a non-fixed VLAN on IOC1-1 with VLAN ID = 99, Priority=5, where the IP
address= 192.168.3.20, Netmask=255.255.255.0, Next Hop=192.168.3.1 and
Destination Network/Net-Prefix=192.168.3.0/24
tp5000> set vlan-config add ioc1-1 non-fixed vlan-id 99
priority 5 address 192.168.3.20 netmask 255.255.255.0
next-hop 192.168.3.1 dest-network 192.168.3.0/24
Example 3:
To modify Index 3 on an existing fixed VLAN on IOC1-1 with the new IP address of
192.168.1.7, Netmask=255.255.255.0, and Gateway=192.168.1.1 
tp5000> set vlan-config modify ioc1-1 index 3 address
192.168.1.7 netmask 255.255.255.0 gateway 192.168.1.1
Example 3a:
To modify the existing non-fixed VLAN with VLAN ID of 99 on IOC1-1 with the new
IP address of 192.168.3.35, Netmask=255.255.255.0, Next Hop=192.168.3.1 and
Destination Network/Net-Prefix=192.168.3.0/24 
tp5000> set vlan-config modify ioc1-1 non-fixed vlan-id 99
address 192.168.3.35 netmask 255.255.255.0 next-hop
192.168.3.1 dest-network 192.168.3.0/24
Example 4:
To Delete the fixed VLAN configuration for Index 4 on port 1 of IOC1 
tp5000> set vlan-config delete ioc1-1 index 4
Example 4a:
Note: In order to Enable the VLAN mode for a port, at least one
VLAN (indexed or non-fixed) must be already be configured and
Enabled on the VLAN for that port. See the set vlan-config
state
command.
