Symmetricom TimeProvider 5000 User Manual

296 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Chapter 4 Provisioning
Provisioning PTP
Unicast - Static
The default condition for Unicast Static is “Disable”. See Table B-30 for default
values for other Unicast Static parameters.
Use the following procedure to configure IOC1, Port 1 for 2 Unicast Static clients:
Client 1: 10.11.11.101, VLAN ID=10, index=1, Clock ID: 0A:11:22:33:44:55:66:77,
Synchronization interval rate = 16 per second (sync-int value = -4) ,
Announce interval rate = 1 per second (
announce-int value = 0),
Delay interval rate = 8 per second (delay-int value = -3)
Client 2: 10.21.21.101, VLAN ID=20, index=2, Clock ID: 0A:22:33:44:55:66:77:88
Synchronization interval rate = 32 per second (sync-int value = -5) ,
Announce interval rate = 1 per second (
announce-int value = 0),
Delay interval rate = 16 per second (delay-int value = -4)
1. Login at the Admin or Config-user level.
2. Type
set ptp profile ioc1-1 telecom-2008 and press Enter.
3. Type
set ptp unicast static address ioc1-1 index 1 10.11.11.101
and press Enter.
4. Type
set ptp unicast static vlanid ioc1-1 index 1 add 10 and press
Enter.
5. Type
set ptp unicast static clockid ioc1-1 index 1
0A:11:22:33:44:55:66:77
and press Enter.
6. Type
set ptp unicast static sync-int ioc1-1 index 1 -4 and press
Enter.
7. Type
set ptp unicast static announce-int ioc1-1 index 1 0 and press
Enter.
8. Type
set ptp unicast static delay-int ioc1-1 index 1 -3 and press
Enter.
9. Type
set ptp unicast static state ioc1-1 index 1 enable and press
Enter.
10.Type
set ptp unicast static address ioc1-1 add index 2
10.21.21.101
and press Enter.
Note: Each VLAN must be configured on a separate subnet. See
Provisioning VLAN and the set vlan command for details.
