098-00028-000 Revision F – May, 2012 TimeProvider 5000 User’s Guide 297
Chapter 4 Provisioning
Provisioning PTP
11.Type set ptp unicast static vlanid ioc1-1 index 2 vlanid 20 and
press Enter.
12.Type
set ptp unicast static clockid ioc1-1 add index 2
0A:22:33:44:55:66:77:88
and press Enter.
13.Type
set ptp unicast static sync-int ioc1-1 index 2 -5 and press
Enter.
14.Type
set ptp unicast static announce-int ioc1-1 index 2 0 and press
Enter.
15.Type
set ptp unicast static delay-int ioc1-1 index 2 -4 and press
Enter.
16.Type
set ptp unicast static state ioc1-1 index 2 enable and press
Enter.
Multicast (Default)
The TP5000 grandmaster operates per the multicast communication model, which
specifies that each PTP message sent from the grandmaster is capable of being
received and processed by all PTP ports on the same PTP communication path.
The “set ptp multicast” command is used to provision parameters specific to
multicast addressing mode (hybrid or Default profile). See Figure 4-13 for the
hierarchy of the “set ptp multicast” commands and Table 4-11 for defaults and
ranges.
In multicast mode, there are no client leases or client limits. All delay requests will
be responded to. There is no limit applied to the number of delay responses
supported, other than the maximum capacity of the Ethernet link and the packet
engine.
Note: If the client is not reachable, the “set ptp unicast static state”
command will fail.
Note: The TP5000 requires a 1.2 feature license key to unlock the
multicast addressing mode feature. Use the
show license current
command to display the current license.
