Symmetricom TimeProvider 5000 User Manual

302 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Chapter 4 Provisioning
Provisioning PTP
Figure 4-14. Set PTP Command Hierarchy  Unicast Dynamic
Figure 4-15. Set PTP Command Hierarchy  Unicast Static
Table 4-10. PTP
 Common Parameter Descriptions
Parameter Description
profile Use to control whether Grandmaster operates with Default
(Multicast), Hybrid (Multicast-hybrid), Telecom-2008
(Unicast), or ITU-G.8265-1 profile for the specified port.
mgmt-addr-mode Use to control whether PTP management messages should
use unicast or multicast. This setting is independent of the
addr-mode. For example, management can be set for
multicast while PTP synchronization is using unicast. For
multicast management, the client must be in the client list.
