Symmetricom TimeProvider 5000 User Manual

098-00028-000 Revision F – May, 2012 TimeProvider 5000 User’s Guide 377
Chapter 6 Maintenance and Troubleshooting
Troubleshooting
Active
Indicates which
IOC is
responsible for
generating PTP,
Telecom, 10MHz,
and 1PPS
outputs
ACT Off - Standby IOC or System
Startup or card failed
If dual IOC cards, then the IOC is
in Startup or in Standby, or card
failed
If single IOC card, then IOC is in
Startup or card failed.
See
Table 6-2 ,“No LED lit on
any module” for probable causes
and more corrective actions.
Check alarms with “show
alarm-config” commands.
Green - Active IOC n/a
IOC Alarm
IOC module
alarm/fault
indicator
ALM Off - IOC operating normally n/a
Flashing Green - Software
starting up
Wait for IOC to finish booting.
Amber - IOC operational Minor
Alarm(s)
Use “show alarm” command to
view alarm IDs and descriptions.
See
Table A-1 in Appendix A,
System Messages
for corrective
actions.
Red - IOC has Failed or has
Major/Critical Alarm(s)
Use “show alarm” command to
view alarm IDs and descriptions.
See
Table A-1 in Appendix A,
System Messages
for corrective
actions. After taking corrective
actions, use “reboot ioc”
command.
Table 6-3. LED Conditions for the IOC (Continued)
Indicator Label Description Corrective Action
