5 Implement application controller setup LH 5000 controller setup
Setting Explanation
Coverage switching overlap The amount of boom switching overlap allowed before the section
will be switched by the system.
Enter a value between 1 - 99%.
Boundary switching
overlap
The amount of overlap on a boundary before the boom section is
switched off.
Enter a value between 1 - 99%.
On/Off valve latency Tune the section switching to allow for hardware delays.
Enter a time between 0.0 - 10.0 seconds.
Intentional overlap Distance to be overlapped when moving to an unsprayed area or
out of a sprayed area.
Enter a distance between 0' 00" - 32' 10" (0.00 - 10.00 m).
Rate control
Setting Explanation
On Application rates are sent from a prescription loaded in the display
or the target rate manually configured on the display.
Off The target rate must be set on the LH 5000 controller. The CFX-750
display does not send target rates to the controller. This is the
default setting.
When sending a target rate to the LH 5000 controller that is higher than 99.9, the display rounds to
the nearest whole number. For example, 0-99.9 is not rounded. 101.4 is rounded to 101.
Target Rate
Set the target application rate that will be sent to the LH 5000 controller. Enter a rate between 0.0 -
11000.0.
Turn Off Rate on Overlap
Setting Explanation
Yes Does not spray over an area that has been previously sprayed.
No Sprays over an area that has been previously sprayed.
106 CFX-750 Display User Guide Version 7.0, Revision A
