Connect the CFX-750 display 2 Installation
g
AG-25 GNSS antenna 77038
h
NMO-to-TNC 20 ft antenna cable and base 62120
i
900 MHz radio antenna kit 22882-10
Also see:Correction services setup, 168.
Install and connect the antenna
Note – To minimize any interference to the GNSS signal, make sure that the GNSS antenna is at
least 1 m (3 ft) from any other antenna (including a radio antenna). You may experience
interference if you operate the vehicle within 100 m (300 ft) of any power line, radar dish, or cell
phone tower.
1.
Find the mounting location for the antenna at the front of the vehicle roof, centered from left
to right.
Note – The AG-25 antenna has integrated magnets for easy installation. To attach the
antenna to a non-metal surface, you must use the mounting plate.
2. On the mounting plate, remove the protective covers from the adhesive strips.
3. Attach the mounting plate to the vehicle roof with the adhesive strips. Ensure that the
mounting plate is centered along the vehicle roof.
4. Connect the antenna cable to the antenna.
5. Place the antenna directly on the mounting plate. The three magnets embedded in the bottom
of the antenna will hold it in place.
6. Route the other end of the antenna cable into the cab.
Version 7.0, Revision A CFX-750 Display User Guide 31
