9 Yield Monitoring setup Yield Monitoring calibration
c. Option Setup:Enables or disables the Start New Load confirmations. If you enable this
setting, the operator has the option to confirm that they want to end the load. If you
disable the setting, the operator is not prompted to confirm the end of the load they tap
the New Load button.
d. Bin Volume: Enter the size of the combine's grain tank.
e. Bin Display Type:Select the option to view the current grain bin capacity in either actual
units or as a percentage of the bin capacity.
f. Map Legend Setup:Enables you to determine the scale on the Yield and Moisture layers
that are displayed on the CFX-750 display.
Yield Monitoring calibration
You must perform calibration of the equipment before going to the field.
Calibrations include:
l Calibrations that are performed before entering the field:
l
l Header Height Calibration (see Header Height Calibration, 158)
l Tare Calibration (see Tare Calibration, 159)
l Temperature Calibration (see Temperature Calibration, 159)
l Roll Calibration(see Roll Calibration, 160)
l Calibrations that must be performed in the field:
l
l Yield Flow Calibration (see Yield flow and moisture sensor calibration, 160)
l Moisture Sensor Calibration
Calibrationsbefore entering the field
The following calibrations are done before you enter the field.
Header Height Calibration
The Header Height Calibration wizard enables you to set the high and low points for the header
height position.
Note – For accurate operation, the highest and lowest point of header operation must fall within
the 0-5 Volt range of the sensor. If the sensor reaches maximum value before the full range of the
header movement, you will need to adjust the linkage on the sensor.
1. At the Yield Monitor Calibration screen, tap Header Height Calibration to start the calibration
wizard.
158 CFX-750 Display User Guide Version 7.0, Revision A
