EZ-Pilot steering system 4 Vehicle guidance setup
Setting Explanation
Maximum Angle The EZ-Pilot system will not engage when the vehicle is heading
toward the guidance line at an angle greater than the Maximum
Angle.
Enter an angle between 5 and 45 degrees.
Engage/Disengage Offline
l Engage offline: The system will not engage when the vehicle is
offline further than this distance. Enter a distance between 0' 5"
and 27' 0" (0.2 and 8.2 m).
l Disengage offline: The system will automatically disengage when
the vehicle is offline further than this distance. Enter a distance
between 0' 6" and 27' 00" (0.2 m and 8.2 m).
Override sensitivity How much force is required to disengage the system. Enter an
increment between 1-100%.
Operator timeout Enter a time between 1-60 minutes.
Vehicle Setup
Setting Explanation
Vehicle type
The type of vehicle on which the EZ-Pilot system will be installed.
Wheelbase
See Vehicle Measurements In
EZ-Pilot system calibration, 64
.
Antenna height
See Vehicle Measurements In
EZ-Pilot system calibration, 64
.
Antenna to axle offset
See Vehicle Measurements In
EZ-Pilot system calibration, 64
.
Freeplay left / right Drives consistently to one side of the line.
l If the vehicle is offline to the left, increase the Freeplay offset to
the right.
l If the vehicle is offline to the right, increase the Freeplay offset
to the left.
Motor speed The speed of the EZ-Pilot drive wheel motor.
Version 7.0, Revision A CFX-750 Display User Guide 63
