13 Operations Auto steering system operation
Auto steering system operation
To receive guidance information (and any assistance from an auto steer system) you must:
l Configure how the guidance displays on your screen. See Auto steering system operation,
below.
l Map a guidance line. See Guidance line / pattern mapping, 203.
l Configure the lightbar. See Lightbar setup in Display settings, 189.
EZ-Steer system operation
Engage the system
Note – Before you can engage the EZ-Steer system, you must:
l Set up and calibrate the system.
l Open a field in the Guidance screen.
l Map an AB line.
l Position the vehicle within the configured engage limits.
1. To engage the system, point the nose of the vehicle toward the guidance line and drive at
operational speed.
2. To engage, you can:
ll
Tap at the Guidance screen.
l Use an external foot or rocker switch (see Foot or rocker switch setup, 85).
Disengage automatically
The EZ-Steer system automatically disengages when:
l The vehicle is outside the configured engage limits.
l You pause the system.
l GNSS positions are lost.
l
You tap on the Guidance screen.
Disengage manually
You can manually disengage the EZ-Steer system by turning the steering wheel (this overrides the
electric motor). Check this setting before you start using the system by engaging on a line and then
turning the wheel until the system disengages. To adjust the amount of force required to disengage
the system, change the Override Sensitivity in the Engage Options screen.
218 CFX-750 Display User Guide Version 7.0, Revision A
