12 System settings Status
After you have entered a valid passcode:
ll The display automatically restarts. Do not disconnect the power from the display while it is
rebooting.
l The Password Upgrade screen displays again with a message that the upgrade was
successful. If you have entered an incorrect password, an error message displays and you
are returned to the Unlock/Upgrade screen.
Unlock features using USBdrive
1. Obtain the unlock code from your Trimble reseller.
2.
Create a ".txt" file on the root of the USB drive named "trimble_unlocks_" followed by the serial
number of the display. For example:trimble_unlocks_5016500025.txt
3. Copy the passcodes into the .txt file you created in Step 2 and save the file.
4.
Go to the Guidance screen and tap in the upper right of the display.
5. Tap Install Unlocks from File and follow the steps in the unlock wizard.
6. After installation, a listing of accepted unlocks will be shown. Then the system will reboot.
Upgrade your display's firmware
1. Transfer the new firmware file from www.trimble.com to your office computer.
2. Connect the USB drive to your office computer.
3. Unzip the firmware file and then save it to the root folder of the USB drive.
4. Insert the USB drive into the USB socket of the display.
5. At the Unlock/Upgrade screen, tap Firmware Upgrade Wizard.
6.
Select the file to upload and then tap . The firmware begins to load.
After the new firmware has successfully loaded, the display automatically restarts. Do not
disconnect the power from the display while it is rebooting.
Status
At the Status screen, you can view the current status of the system.
Note – The items that display in the Status screen vary according to the features that you use.
Tap... To view...
Language Pack status
The language packs that have been installed on the display
196 CFX-750 Display User Guide Version 7.0, Revision A
