Trimble CFX-750 - Chapter 2 Installation

Installation
In this chapter:
System components 26
Install the CFX-750 display 27
Connect the CFX-750 display 29
Install external foot/rocker switch 32
To install the CFX-750 display as a
standalone system, you install the mount,
display and antenna. Optionally, you can
install an external foot / rocker switch.
2
C h a p t e r
CFX-750 Display User Guide 3
