Bogballe controller setup 5 Implement application controller setup
Bogballe controller setup
The CFX-750 display is compatible with Bogballe Calibrator ZURF, ICON, and UNIQ controllers.
1. After you select Bogballe as your controller, the Output Port screen displays.
2.
Choose the port you want to configure.
Note – Do not configure the display to output NMEA messages on the same port that your
controller is connected to.
3.
On the Bogballe controller, press Return / Return / Fertil.-Distrib / Select Type / Bogballe E/EX /
Accept
For more information on setting up the Bogballe controller, refer to the Bogballe instruction
manual.
Advanced
Use the Advanced option at the Implement screen to configure:
l Boom Setup
l Swath Control
l Rate Control
l Target Rate
l Single Section Boom Switching
Boom Setup
Note – The boom setup on the CFX-750 display must match the setup on the LH 5000 controller. If
the boom setup differs between the display and the LH 5000 controller, a warning message
displays.
Setting Explanation
Implement width Enter a width between 1' 00" - 328' 01" (0.30 - 99.99 m).
Fence Nozzles Enter the locations of any fence nozzles.
Number of sections Enter a number between 1 - 10.
Version 7.0, Revision A CFX-750 Display User Guide 111
