EZ-Steer steering system 4 Vehicle guidance setup
Setting Explanation
Maximum Angle The system will not engage when the vehicle is heading toward the
guidance line at an angle greater than the Maximum Angle.
Enter an angle between 5 and 45 degrees.
Engage/Disengage Offline
l Engage offline: The system will not engage when the vehicles
distance from the guidance line is offline further than this
distance. Enter a distance between 0' 5" and 27' 0" (0.2 and
8.2m).
l Disengage offline: The system will automatically disengage when
the vehicle is offline further than this distance. Enter a distance
between 0' 6" and 27' 00" (0.2 m and 8.2 m).
Engage/Disengage Offline
l Engage offline: The system will not engage when the vehicle is
offline further than the Engage Offline distance. Enter a distance
between 0' 5" and 27' 0" (0.2 and 8.2m).
l Disengage offline: The system will automatically disengage when
the vehicle is offline further than the Disengage Offline distance.
Enter a distance between 0' 6" and 27' 00" (0.2 m and 8.2 m).
Override sensitivity How much force is required to disengage the system. Enter an
increment between 1-100%.
EZ-Steer external switch Enable or disable additional safety features.
EZ-Steer operator timeout Enter a time between 1-60 minutes.
Vehicle Setup
Setting Explanation
Vehicle type Enter the type of vehicle on which the EZ-Steer system will be
installed.
Wheelbase See Vehicle Measurements in EZ-Steer system calibration, 59
Antenna height
See Vehicle Measurements in
EZ-Steer system calibration, 59
Antenna to axle offset
See Vehicle Measurements in
EZ-Steer system calibration, 59
Angle per turn Adjust the angle that the wheels turn during one full rotation of the
steering wheel.
Enter an angle between 2-149 degrees.
Version 7.0, Revision A CFX-750 Display User Guide 57
