Foot or rocker switch setup 4 Vehicle guidance setup
1.
At the Guidance screen, tap .
2.
At the Settings screen, tap .
3. At the Vehicle screen, tap Auto Steer Setup.
4. At the Auto Steer Setup screen, Save / Restore Configuration.
5. From the Save/Restore Configuration screen, tap the option you need:
ll Save Vehicle Configuration to save a vehicle configuration to the external memory or
internal memory of the display
l
Restore Vehicle Configuration to restore a previously saved configuration file
Note – Configuration files will be recognized if they are copied from an FmX® integrated
display and are within the original content folder created by the FmX® integrated display.
l
Delete Vehicle Configuration to delete a configuration profiles from external memory or
internal memory
A setup wizard will take you through each of the configuration options.
Note – The internal memory of the display can only store a maximum of 10 unique vehicle
configurations. External memory options are only available if a USB device is present in the rear
port of the display.
Foot or rocker switch setup
To set up the foot or rocker switch:
1.
At the Guidance screen, tap .
2.
At the Settings screen, tap .
3. At the Vehicle screen, tap AutoSteer.
4. At the Auto Steer screen, tap EZ-Pilot Setup.
5. Tap EZ-Pilot External Switch. The Engage Options screen displays.
6. Tap External Switch.
7.
At the External Switch screen, tap Remote Engage and then tap .
Version 7.0, Revision A CFX-750 Display User Guide 85
