EZ-Steer steering system 4 Vehicle guidance setup
EZ-Steer Demo
Note – EZ-Steer Demo Mode requires an EZ-Steer controller, motor, and EZ-Steer simulator stand
(P/N 54836-00).
This option is available if you have loaded the vehicle demo type from the Vehicle Database (VDB).
(See Load VDB, 70.)
EZ-Steer Demo Mode is useful for practice with defining fields, coverage logging, and assisted
steering.
EZ-Steer system calibration
Before you begin to use the CFX-750 display with the EZ-Steer system, you must complete
calibration steps.
To do this, complete the Quick Start Wizard (see Quick start wizard, 39) that displays the first time
you use the CFX-750 display.
Note – You must have GNSS connected to complete calibration.
1. First set up the EZ-Steer system (see EZ-Steer system setup, 56).
2.
At the Guidance screen, tap .
3.
At the Settings screen, tap .
4.
At the Vehicle screen,tap Auto Steer Setup.
5. At the EZ-Steer Setup screen, tap EZ-Steer Calibration Wizard.
The wizard guides you through:
l Vehicle measurements
l T2® roll calibration
l EZ-Steer system calibration
Vehicle measurements
For optimum guidance, you must take accurate vehicle measurements and enter them into the
display.
Note – Do not enter calibration numbers from EZ-Guide® Plus or EZ-Steer® T2 systems. This may
cause very poor vehicle control, including swerves and/or large oscillations.
To streamline the calibration process, you may want to take the vehicle measurements and record
them for entry later on.
The techniques for taking vehicle measurements are described as follows. Also see EZ-Steer system
setup, 56 for information on vehicle measurements.
Version 7.0, Revision A CFX-750 Display User Guide 59
