Trimble CFX-750 - Position quality; GNSS advanced settings

Position quality 10 GNSS setup
VRSConnection Status Explanation
Logged in VRS connected
Connecting Mobile network - Searching
Disconnected Mobile network - No service
Position quality
GNSS signals can be disrupted by foliage, or when the machine moves out of sight of one or more
satellites, or when one or more satellites move out of sight of the machine or ‘set’ below the
horizon.
The Position Quality screen provides options that allow you to operate when the quality of GNSS
position information is compromised. Options are:
l Favor Accuracy:Provides the highest level of accuracy
l Balanced Quality:Trades potential accuracy for a slight increase in production time
l Favor Availability:Extends production time further, with more potential for reduced accuracy
GNSSadvanced settings
At the Advanced screen, you can view and adjust advanced GNSS settings.
Setting Explanation
Antenna Type
At the Antenna Type screen, change the internal settings of the GNSS
receiver to ensure optimum accuracy for the antenna.
Select the antenna you have connected to the display.
Note – The AG-25 antenna is white and dome shaped.
Use SBAS satellites in
the position fix
Choose this option if you want to use SBAS corrections from WAAS
satellites to calculate the GNSS positions. For example, if the display
receives position information from six standard GNSS satellites and two
WAAS satellites, the display uses all eight satellites to calculate the GNSS
position.
This can extend operating time when limited number of satellites are
available.
Note – This option does not work with EGNOS satellites, OmniSTAR, or
RTK corrections.
Version 7.0, Revision A CFX-750 Display User Guide 173
