Trimble CFX-750 - Field-IQ Operation (continued); LED Status Lights

13 Operations Field-IQ operation
l In the on/up position:The section(s) assigned to it are commanded to be on. This overrides the
CFX-750 display and coverage logging is ignored.
l In the off/down position:The section(s) assigned to it are commanded to be off. This overrides
the CFX-750 display and coverage logging is ignored.
LEDstatus lights
The LED status indicators are:
l Green: The unit is powered and is communicating with the display.
l Yellow: The unit is initializing communications with the display.
l Red: The unit is powered but not communicating with the display.
