4 Vehicle guidance setup Autopilot steering system
Autopilot Operation
Operation Category Explanation
Online
Aggressiveness
How quickly the guidance system steers onto an active guidance line.
Operator Alert
Timeout
The maximum time interval that the operator can operate without the
guidance system asking for operator presence.
End of Row
Warning
The distance from the end of the row at which the audible warning sounds to
alert the operator of the upcoming event.
Autopilot
Steering Sensor
l Select AutoDense steering sensors or Potentiometer sensors based on
the selected Autopilot profile.
l Set up an AutoSense steering sensor.
Note – To calibrate a potentiometer, select Auto Steer Setup / Autopilot
Setup / Steering Sensor Calibration.
Autopilot Steering Sensor
Note – The Autopilot Steering Sensor type is set based on the .vdb profile or through the activation
of TAP parameters.
Choose the type of Autopilot sensor installed on the vehicle and set up Autosense sensors.
To set up Autosense Steering sensors:
1. Tap AutoPilot AutoSense Location.
2. Choose which axle and side of the vehicle the sensor is mounted upon when viewed from the
operator's seat.
3. Tap AutoPilot AutoSense Orientation.
4. Choose which way the sensor label is facing when viewed from the perspective of looking down
on the sensor.
5.
Tap .
Note – Potentiometer Steering Sensors are calibrated in Autopilot Setup.
Status/Diagnostics for the Autopilot system
To view the system and sensor status settings for the Autopilot system:
82 CFX-750 Display User Guide Version 7.0, Revision A
