System Status 6 Field-IQ crop input control setup
Sensor Type Screen Explanation
Pressure sensor
Input Location
Select where the sensor is connected on the
module.
RPMsensor
RPMCalibration
Enter the Pulse per Revolution number for the
RPM sensor.
Bin state sensor
Alarm on Change
Select the change of state that will trigger the
sensor alarm:
ll Low to High: The alarm is triggered when
the module sees the sensor go from 0V
to 12V.
l High to Low: The alarm is triggered when
the module sees the sensor go from 12V
to 0V.
Bin status sensor
Alarm Text
Enter the text you want to display when the
alarm is triggered.
5. At the Enable Sensor screen, enable or disable the sensor.
6.
At the Sensor Summary screen, review the summary. If all settings are correct, tap .
System Status
Select this option to view the status for:
l Master Switch Module
l Section Switch Module
l Rate Control Module
l Section Control Module
l OEM Switch Interface
l Accessories
Hydraulics Test
WARNING – MOVING PARTS DURING THIS TEST! Please stay clear of the implement. Ensure the implement is
raised, the transmission is in PARK, and the emergency brake is applied before continuing.
