Operate implement controllers 13 Operations
Actual rate The actual application rate.
This is the amount of product that is currently being
applied.
Boom section status
indicators
Shows the current state of each boom section:
l Green: Enabled and spraying
l Gray: Enabled but not currently spraying
l Red: The section is off (the switch is off)
Application indicator The wheel on the display spins when the Amazone
master switch is on and the lightbar receives flow
messages from the controller.
Target Rate
To manually enter a rate to send to the controller:
1.
At the Settings screen, tap .
2. At the Implement screen, tap Advanced.
3. Tap Target Rate and then adjust the rate that is sent to the controller.
Automatic Boom Switching
The CFX-750 display does not perform automatic boom switching for the Raven controller.
Note – To ensure that areas outside the headland, in exclusion zones, or previously sprayed areas
are not sprayed, you will need to manually turn off the Raven controller master switch.
Rawson controller operation
When you connect the Rawson controller to the display, the following displays on the Guidance
screen.
Button/Information Name Explanation
Quick Access button
Opens additional controls.
See Quick access button for Field-IQ, 231.
Version 7.0, Revision A CFX-750 Display User Guide 241
