Trimble CFX-750 - T3 terrain compensation calibration; Angle Per Turn calibration; EZ-Pilot system calibration

EZ-Pilot steering system 4 Vehicle guidance setup
T3 terrain compensation calibration
The T3 roll sensor enables the display to handle terrain compensation in the IMD-600 unit.
1.
Enter an accurate value for the IMD-600 orientation.
2. Park the vehicle and mark the inside of both sets of wheels.
3. Remain stationary while the system calculates the roll offset. This takes approximately 20
seconds.
4. Turn the vehicle around and ensure the wheels are over the positions marked in the previous
step.
5. Remain stationary while the system calculates the roll offset. This takes approximately 20
seconds.
Angle Per Turn calibration
First set the IMD-600 orientation and perform the T3 terrain compensation calibration.
You must operate the vehicle in an open field with ample area for the vehicle to make right and left
turns.
1. Tap Right Angle-Per-Turn Calibration.
2.
Drive forward until (yellow) displays and then tap the icon.
Note – For the best results drive the vehicle between 2 and 4 mph.
Allow the system to operate for 20 seconds until you receive a message that the calibration is
complete.
3. Repeat Step1 through Step2 for left angle-per-turn calibration.
EZ-Pilot system calibration
1.
In a clear field, begin driving and tap .
2.
Drive 160 feet and then tap .
A series of calibration screens enable you to adjust any settings as necessary.
Version 7.0, Revision A CFX-750 Display User Guide 67
