13 Operations Operate implement controllers
Button/Information Name Explanation
Target rate The target application rate for the current rate switch
position.
This is the amount of product that you want to
apply.
If a prescription is loaded, P displays to indicate that
the prescription rate is being used rather than the
target rate.
Actual rate The actual application rate.
This is the amount of product that is currently being
applied.
Boom section status
indicators
Shows the current state of each boom section:
l Green: Enabled and spraying
l Gray: Enabled but not currently spraying
l Red: The section is off (the switch is off)
Application indicator The wheel on the display spins when the Amazone
master switch is on and the lightbar receives flow
messages from the controller.
Raven controller operation
When you connect the Raven controller to the CFX-750 display, the following displays on the
Guidance screen.
Button/Information Name Explanation
Quick Access button
Opens additional controls.
See Quick access button for Field-IQ, 231.
Target rate The target application rate for the current rate switch
position.
This is the amount of product that you want to
apply.
If a prescription is loaded, P displays to indicate that
the prescription rate is being used rather than the
target rate.
240 CFX-750 Display User Guide Version 7.0, Revision A
