EZ-Steer steering system 4 Vehicle guidance setup
T2 roll calibration
T2 roll sensor calibration enables the display to handle terrain compensation in the EZ-Steer
controller. This step requires you to:
1. Enter an accurate value for controller orientation.
2. Park the vehicle and mark the inside of both sets of wheels.
3. Remain stationary while the system calculates the roll offset. This takes approximately 20
seconds.
4. Turn the vehicle around and ensure the wheels are over the positions marked in the previous
step.
5. Remain stationary while the system calculates the roll offset. This takes approximately 20
seconds.
EZ-Steer system calibration
In this step you must drive and engage on a straight AB line in a clear field:
1.
Begin driving and then tap .
2.
Drive 160 feet and then tap . A series of calibration screens will allow you to adjust any
settings as necessary.
Version 7.0, Revision A CFX-750 Display User Guide 61
