Trimble CFX-750 - HARDI 5500; 6500 controller setup; Advanced; Boom Setup

5 Implement application controller setup HARDI 5500 / 6500 controller setup
HARDI 5500 / 6500 controller setup
Note – For the HARDI 5500 / 6500 controller to work correctly with the CFX-750 display, you must
install firmware version 6.00 or greater on the HARDI controller and connect a JOBCOM control
box.
1.
After you select the HARDI 5500 or HARDI6500 as your controller, the Output Port screen
displays.
2. Choose the port you want to use.
3.
Set up the display to output NMEAmessages. (See NMEA Output at Advanced display settings,
192.)
Note – Do not configure the display to output NMEA messages on the same port that your
controller is connected to.
4. On the HARDI 5500/HARDI6500 controller, go to the Settings screen.
5. Change Remote to Enable.
For more information on setting up the HARDI 5500/HARDI6500 controller, refer to the HARDI
instruction manual.
Advanced
Use the Advanced option in the Implement screen to set up:
l Boom Setup
l Swath Control
l Rate Control
l Off When Stopped
l Rate Snapping
Boom Setup
The boom setup on the CFX-750 display must match the setup on the HARDI controller. If the boom
setup differs between the display and the HARDI controller, a warning message displays.
Setting Explanation
Implement width Enter a width between 1' 00" - 328' 01" (0.30 - 99.99 m).
Fence Nozzles Enter the locations of any fence nozzles.
Number of sections Enter a number between 1 - 10.
