13 Operations Auto steering system operation
1. To engage the system, point the nose of the vehicle toward the guidance line and drive at
operational speed.
2. To engage, you can:
ll
Tap at the Guidance screen.
l Press the engage button on the optional remote control.
l Use an external foot or rocker switch (see Foot or rocker switch setup, 85).
CAUTION – If you use the vehicle on a public roadway, you must put the red EZ-Pilot system override switch in the
off position.
Disengage automatically
The EZ-Pilot system automatically disengages when:
l The vehicle is outside the configured engage limits.
l You pause the system.
l GNSS positions are lost.
l
You tap the button on the Guidance screen.
l You press the Engage button on the optional EZ-Remote joystick.
Disengage manually
You can manually disengage the EZ-Pilot system by turning the steering wheel. This overrides the
electric motor.
Check this setting before you start using the system by engaging on a line and then turning the
wheel until the system disengages.
To adjust the amount of force required to disengage the system, change the Override Sensitivity in
the Engage Options screen. See EZ-Pilot system setup, 62.
Engage on-screen control
Button/Indicator Tap to... Indicates...
(Yellow)
Engage the auto steering system System is ready to engage
222 CFX-750 Display User Guide Version 7.0, Revision A
