Operate implement controllers 13 Operations
Button/Information Name Explanation
Target rate The target application rate for the current rate switch
position.
This is the amount of product that you want to
apply.
If a prescription is loaded, P displays to indicate that
the prescription rate is being used rather than the
target rate.
Actual rate As the HARDI controller does not report the actual
applied rate to the display, this item always displays
as N/A.
Boom section status
indicators
Shows the current state of each boom section:
l Green: Enabled and spraying
l Gray: Enabled but not currently spraying
l Red: The section is off (the switch is off)
Application indicator The wheel on the display spins when the HARDI
master switch is on and the booms are on.
Fence nozzle
indicator
This indicator displays only when a fence nozzle is
enabled. Fence nozzle status is represented with the
same colors as the boom sections (see below).
The CFX-750 display cannot automatically turn fence
nozzles on or off. It only displays the current status.
LH5000 controller operation
When the LH 5000 variable rate controller is connected to the display, the following displays on the
Guidance screen.
Button/Information Name Explanation
Quick Access button
Opens additional controls.
See Quick access button for Field-IQ, 231.
Version 7.0, Revision A CFX-750 Display User Guide 239
